High-tech Filtration, Separation and Purification
Softdrinks Filtration
Liquid and Gas Coalescing Filter
LG coalescing filters protect downstream equipment and processes from compressor wear products, lubrication oil, water or other liquid droplets, corrosion products and other particulate contaminants, while reducing maintenance costs. These filter catridges are designed for critical air or gas service applications where high effciency removal of oil or water droplets and particulate solids.
Powder-Activated Carbon
This filter is used to remove oil vapor, organics, taste, and odor in compressor air.
Removal of Particles
They provide up to HEPA Quality air and gas filtration with hydrophobic polypropylene-graded density depth medium with superior flow rates, lower pressure drops, higher capacity and longer filter life. Removes absolute particle rated 0.3 micron.
Sterilizing-grade Filter Cartridge
They are designed to completely remove bacteria, viruses and particles from air and gas streams, even in the presence of humidity and moisture. Also retains 100% of Brevundimonas diminuta bacteria, bacteriophage and virus aerosols.
Metal Filter Cartridge
The metal filter cartridges are made from fine stainless steel powders sintered to form rugged high voids and fixed pore filters with high temperature, pressure and solvent resistance. Particle removal at: 0.4,0.8,1.3,11, 20,25,55,85,175, and 350 micron.
Other Filters
The filter element is used for sterile filtration of compressed air, process air, technical gases and vent applications. The retention rate is 99.99998% for all particles 0.01µm and larger, ensuring safe and sterile filtration of process gases. The filter element provides low pressure drop, high dirt-holding capacity, great strength, and long service life to dramatically reduce your operating costs. This element is used in compressed air and gas applications, including tank ventilation.
Incoming Water Treatment for Softdrinks Production
Critical to the absolute purity of your finished product is filtration at every stage, including prefiltration of raw water as it enters the process. Pall has addressed your need for an economical and reliable particulate filter systems designed for the following applications.
Conventional water treatment upstream of nanofiltration and reverse-osmosis systems can include sand filtration, flocculations, ion exchange resins and cartridge filtration. For a more economical and reliable approach, Pall has developed a compact system that uses Hollow Fiber modules for the replacement of most conventional water treatment steps upstream of reverse osmosis or nanofiltration.
Particulate Control for Flavor Additive
Profile Star filter cartridges are pleated depth filters designed for high particle removal efficiency in food and beverage applications.
The Profile Star filter cartridge combines the advantages of a continuously graded pore structure and a unique pleated geometry to provide an increase in effective filtration area and service life.
The pressure drop and flow capability is comparable to competitive pleated polypropylene filters whilst also providing excellent removal of soft contaminants (e.g. gels) because of the depth of the medium.
Ultipleat High-Flow Filter
The filter is specially designed for high flow applications (>10 m/h). Compared with conventional cartridges, fewer elements are required for a given flow rate, avoiding the use of large housings and enabling major savings in capital, maintenance and operating costs.
Reproducible and consistent absolute rating (ß>5000). Size remove: from 1 micron to 20 micron
Particle Depth Filter Cartridge
These filter cartridges are high efficiency depth style filters constructed of polypropylene. Constructed of polypropylene, with a continuously graded fixed pore structure, these cartridges provide pre- and final filtration within the same cartridge resulting in lower overall filtration and disposal cost.
The filter cartridges provide a removal efficiency of >99.98% in compatible liquids with consistent filtration performance.
Size remove: from 0.5 micron to 100 micron
Particle-pleated Filter Cartridge
The filter cartridges are all-polypropylene pleated filters with high flow and high contaminant holding capacity for longer on-stream life. The filter media is produced by using a proprietary melt-blowing process that delivers exceptional product consistency. It is ideally suited to the capture of non-deformable particles from compatible liquid or inert gas feed streams, characterized by a narrow particle size. Size remove : from 0.2 micron to 50 micron
Depth Filter Sheets
The series depth filter sheets were developed to meet the production needs and requirements of the brewing industry.
From the selection and quality control of raw materials to application of the latest production technologies, the series filter sheets meet the highest quality standards. The high stability of BS series filter sheets enables long production runs and fulfills the specific requirements of the brewing industry.
The series filter sheets are available in multiple grades suitable for polishing and microbial reduction applications within breweries.
